Photovoltaic (Solar Grade) Quartz Crucibles
Inquiry
Product introduction
The purity requirements for photovoltaic quartz crucibles are relatively low. Generally, the SiO2 purity is required to be above 99.95%, the impurity content is below 100ppm, and the gas-liquid inclusion content is below 500ppm.
Product parameters
| Pecification (inch) | Diameter D (mm) | Height H (mm) | Straight Wall Thickness W1 (mm) | Curved Wall Thickness W2 (mm) | Base Thickness W3 (mm) | Curved Radius R1 (mm) | Curved Radius R2 (mm) |
|---|---|---|---|---|---|---|---|
| 14 | 355±2 | 240±3 | 10±3 | 10±3 | 11±3 | 89 | 381 |
| 16 | 405±2 | 280±3 | 9.0±2 | 9.0±2 | 9.0±2 | 90 | 450 |
| 18 | 457±2 | 355±2 | 7-12 | 7-12 | 7-12 | 88-120 | 457-500 |
| 20 | 505±2 | 385±3 | 11.0±2 | 11.0±2 | 11.0±2 | 120 | 508 |
| 22 | 555-560 | 406±3 | 11 (+3/-1) | 11 (+3/-1) | 11 (+3/-1) | 127 | 560 |
| 24 | 609 (+2/-3) | 440±3 | 11 (-2/+3) | 12 (-2/+3) | 12 (-2/+3) | 120 | 610 |
| 26 | 654±3 | 500±3 | 12 (+3/-1) | 12 (+3/-1) | 14 (+4/-2) | 120 | 660 |
| 28 | 708±3 | 556±3 | 13.5±2 | 13.5±2 | 19.0±3 | 120 | 710 |
| Spec | Diameter D (mm) | Height H (mm) | Straight Wall Thickness W1 (mm) | Curved Wall Thickness W2 (mm) | Bottom Thickness W3 (mm) | Curved Wall Diameter R1 (mm) | Curved Wall Diameter R2 (mm) |
|---|---|---|---|---|---|---|---|
| 14inch | 355±2 | 240±3 | 10±3 | 10±3 | 11±3 | 89 | 381 |
| 16inch | 405±2 | 280±3 | 9.0±2 | 9.0±2 | 9.0±2 | 90 | 450 |
| 18inch | 457±2 | 355±2 | 7 - 12 | 7 - 12 | 7 - 12 | 88 - 120 | 457 - 500 |
| 20inch | 505±2 | 385±3 | 11.0±2 | 11.0±2 | 11.0±2 | 120 | 508 |
| 22inch | 555 - 560 | 406±3 | 11+3/-1 | 11+3/-1 | 11+3/-1 | 127 | 560 |
| 24inch | 609+2/-3 | 440±3 | 11 - 2/+3 | 12 - 2/+3 | 12 - 2/+3 | 120 | 610 |
| 26inch | 654±3 | 500±3 | 12+3/-1 | 12+3/-1 | 14+4/-2 | 120 | 660 |
| 28inch | 708±3 | 556±3 | 13.5±2 | 13.5±2 | 19.0±3 | 120 | 710 |
